Gas Mixer KM100-200_2M

Gas mixer for 2 gases, especially for Modified Atmosphere Packaging

  • quality gas mixer from the market leader
  • for continuous gas withdrawal
  • infinitely variable mixing and flow settings
  • different capacity ranges
  • independent of pressure fluctuations and packing speed
  • monitoring of the gas supply by pressure switch
  • integrated inlet pressure monitoring
  • gas supply monitoring
  • variable outlet pressure regulation
  • suitable for food-grade gases according to regulation (EC) No. 1935/2004, company certified according to DIN EN ISO 22000

Data sheet Downloads
Quotation request

Information

Gas mixing systems for 2 defined gases especially for flow packing machines or other continuous packaging processes in the food industry.
Capacity range up to approx. 684 SCFH.
For the exact pressure and flow capacity ratios, please see the technical data overleaf.

Easy operation:

  • a proportional mixing valve (-2) with a control knob and %-scale provides infinitely variable mixture settings
  • the flow of the gas mixture is controlled by a metering valve combined with a flow meter

Constant quality:

  • independent of pressure fluctuations in the gas supply
  • independent of packing speed (in permitted range)

High process reliability:

  • alarm module NXT+: integrated inlet pressure monitoring with digital display for pressure (with analog pressure transmitters) plus optical alarm, adjustable alarm limits, obligation of acknowledgement, protection of alarms, interfaces for controlling external alarms etc.
  • lockable transparent door for protection of settings

Maximum hygiene:

  • splash-proof and robust stainless steel housing
  • smooth and easy to clean surface

Other models, options and accessories available upon request. Please identify the individual gases at the time of enquiring!

Our gas mixers are always customized to the needs of the costumer. Please tell us your specifications, we will realize them.

Accessories

Inline Gas Analyzer

Plug-in module for permanent analysis of gas mixture, e.g. for CO2, O2, H2, He
