Gas Analyzer OXYBABY® 6.0

O2- and O2/CO2-gas analyzer for MAP-packages, premium version

  • ideal for quality control
  • fast and precise sample testing
  • also measures packaging pressure
  • minimum sample gas requirement (2 ml)
  • O2 value is displayed in 0,01% steps
  • long lifetime of O2 sensor (approx. 2 years, depending on use)
  • high capacity data storage, with export port
  • low follow-up costs: easy sensor replacement and calibration by user
  • can be used as a tabletop unit by simply inserting a hose
  • optional: software for data management and analysis, bluetooth etc.

Further information on www.oxybaby.com

Data sheet Downloads
Quotation request

Information

Cordless handheld oxygen or combined oxygen/carbon dioxide analyzer for checking modifi ed atmospheres in food packaging. The ideal instrument for portable, fast and accurate sample tests at the packaging machine, in stores or in laboratories.

OXYBABY® is a cost effective mobile alternative to tabletop / fixed analyzers.It offers all of the benefits of modern technology quickly and easily as options.
For example: Bluetooth for wireless communication and an integrated barcode reader.
Ensure that the quality of your packaged product is maintained (HACCP), guaranteeing continued customer satisfaction.
OXYBABY® 6.0 is the ideal instrument for sample tests, requiring only a minimal amount of sample gas, allowing even the smallest of MAP packages to be tested.
Includes measurement of the package’s internal gas pressure. Together with the exclusive OBCC software (optional), measured results can be documented, providing complete traceability (HACCP). Provide your customer with the results, ensuring that your product has the best possible packaging quality.

Benefits

  • minimal sample gas requirement for testing even the smallest packages
  • integrated data log of the last 500 measurements
  • product administration up to 25 users, 100 product names and 50 packaging lines
  • increased memory capacity and simplifi ed data export of measurement results by microSD card
  • indication of package’s internal pressure
  • indication of carrier gas proportion
  • cordless operation using rechargeable batteries
  • data transfer and charge of batteries via USB port
  • sample flow control with warning in case of blocked needle
  • upgraded simple one-hand operation
  • measurement alternatively also by hose
  • easy to clean
  • large illuminated graphic display
  • multilingual menu guide: see overleaf
  • integrated needle cover to protect needle and user
  • long lifetime of O2 sensor (approx. 2 years)
  • low maintenance costs

Complete in carrying case:

  • charging device, microSD card
  • link to OBCC software (demo version)
  • 15 spare needles
  • 5 spare filters
  • set of 100 rubber seals

case dimensions (HxWxD): approx. 325x385x115 mm (12.79x15.16x4.53 inch),
case weight: approx. 1.7 kg

Options:

  • hose with Luer-Lok connection for stationary measurement
  • Bluetooth for OXYBABY® - integrated into OXYBABY®
  • Bluetooth adapter for PC
  • Bluetooth printer
  • OBCC software license
  • can/bottle piercer
  • table rack/stand

Please note our variety of accessories.

Accessories

Inspection OXYBABY / PA

Calibration and maintenance - choose our definitive maintenance package

Aquacheck

OXYBABY® accessories for analysis of very small packages

Can-Piercer

OXYBABY® accessories for headspace analysis of canisters, bottles and cans

Consumables

Rubber seals, needles, sensors etc. for OXYBABY®, PA, MAPY, OXYPAD

Software OBCC

Software for documentation of measurement results of OXYBABY® 6.0 and PA

Table stand

Stainless Steel table stand for OXYBABY®

Table Printer

Bluetooth table printer for OXYBABY® 6.0
