Gasanalyser OXYBABY® 6.0

Female Scientist Working on her Computers (Mock-up Green Screen) In Modern Laboratory. Various Shelves with Beakers, Chemicals and Different Technical Equipment is Visible.

Datablad Offerte aanvraag

O2-of O2/CO2-Gasanalyser voor MAP-verpakkingen, premiumversie

ideaal voor kwaliteitscontrole
snelle, preciese meting
meet eveneens de gasdruk in de verpakking
weinig meetgas nodig (2 ml)
uitlezing van de O2-waarde in stapjes van 0,01%
lange levensduur van de O2-Sensor (ca. 2 jaar, afhankelijk van het gebruik)
groot geheugen voor meetwaarden met exportfunctie
lage verbruikskosten: eenvoudige vervanging en kalibratie van de sensor door de gebruiker
kan worden gebruikt als tafelmodel door het aansluiten van een slang
optioneel: Software voor het vastleggen van uw meetwaarden, bluetooth, Barcode-Reader etc.

Verdere informatie onder www.oxybaby.com

Informatie

Cordless handheld oxygen or combined oxygen and carbon dioxide gas analyser for checking modified atmospheres in food packs. The ideal instrument for portable, faster and accurate sample tests of the headspace at the packaging machine, in stores or in laboratories.

OXYBABY® headspace gas analyser a cost effective mobile alternative to tabletop / fixed headspace gas analysers for welding and food technology.
It offers all benefits of modern technology quickly and easily by option. For example: Bluetooth for wireless communication and an integrated barcode reader.
Ensure that the quality of packaged product is maintained (HACCP), and thus guarantee continued customer satisfaction. The ideal instrument for sample headspace tests with a minimum sample gas requirement, allowing the smallest of modified atmosphere packages (MAP) to be tested for residual oxygen in their headspace. Information of internal pressure in the package via pressure indication. Together with the exclusive OBCC-Software, the measured results can be documented providing complete traceability (HACCP). Provide your customer with the results ensuring that your product has the best possible pack quality.

Benefits:

minimum sample gas requirement for smallest packs with small headspace
integrated data log of the last 500 measurements
product administration up to 25 users, 100 product names and 50 packaging lines
increased memory capacity and simplifi ed data export of measurement results by microSD card
alternatively a pressure indication can be selected
cordless operation using rechargeable batteries
data transfer and charge of batteries via USB port
faster workflow enabled by an optional integrated bar code scanner for product data
sample flow control with warning in case of blocked needle
upgraded simple one-handed operation
measurement alternatively also by hose
easy to clean
large illuminated graphic display
multilingual menu guide
integrated needle cover to protect the needle and user
long lifetime of O2 sensor (approx. 2 years)
low maintenance costs

Complete in carrying case:

charging device
link to OBCC software (demo version)
2 spare needles
2 spare filters
set of 100 rubber seals

case dimensions (HxWxD): approx. 325x385x115 mm (12.79x15.16x4.53 inch),
case weight: approx. 1.7 kg

Options:

hose with Luer-Lok connection for stationary measurement
data cable
integrated Barcode-Scanner
Bluetooth (e.g. for separate printer)

Please note our variety of accessories.
